PPC-S122


12.1" Fanless Multi-touch Waterproof Panel PC with Intel® Celeron® J1900 Processor

Arestech's PPC-S122 is an industrial grade 12.1" LED multi-touch waterproof Panel PC. The stainless steel front panel protects the PPC-S122 from weathering and oxidation. The exceptionally strong bond between the touch-panel and front panel gives the PPC-S122 an IP65 waterproof rating. The slim 2.5 mm front cover makes wall mounting easy. Designed with an Intel® Celeron® Bay Trail D J1900 2.0 GHz processor, the PPC-S122 delivers exceptional performance at low power. Additionally, the PPC-S122's four COM ports can make factory automation control easier. The PPC-S122 is the best choice for use in CNC control panels, the food industry, and outdoor kiosk applications.

Features

  • 12.1" SVGA LED Panel with Projected Capacitive Touch Display
  • Supports Two-finger Touch Control while Wearing Gloves
  • Intel® Celeron® J1900 2.0 GHz Processor
  • Completely Flat Front Design
  • Stainless Steel IP65 Waterproof Front Cover
  • Panel and VESA Mounting

Applications

  • CNC Control Panel
  • Food Industry Management System
  • Animal Feed Production Facility
  • Outdoor Kiosk

Product Features

Model PPC-S122P PPC-S122R
Processor System CPU Intel® Celeron® Processor J1900
Frequency Quad-Core up to 2.0 GHz
L2 Cache 2 MB
System Chipset N/A
BIOS UEFI
Memory Technology DDR3L 1333 MHz SDRAM
Max. Capacity 8 GB
Socket 1 (204-pin SO-DIMM)
Display Panel Size 12.1” LED Panel
Resolution 800 x 600 (SVGA)
Viewing Angle 80 x 80 (H) x 60 x 80 (V)
Brightness 450 (cd/m2)
Color Support 16.7M
Contrast Ratio 800:1
Response Time 30 (msec)
VGA Up to 1920 x 1200
HDMI HDMI 1.4a up to 1920 x 1200
Dual Display LCD + VGA or LCD + HDMI
Touchscreen Touchscreen Type Projected Capacitive 5-Wire Resistive
Surface Hardness 7 3
Surface Hardness - 10 millions times
Transparency 90% (±3%) 80% (±3%)
I/O Interface USB 2 USB 2.0, 2 USB 3.0
Serial Port 4 COM (3 RS-232, 1 RS-232/422/485)
Digital I/O
(Optional)
8-pin Digital I/O (DB-9 connector)
Expansion 2 Mini PCIe (half-size)
Ethernet Controller Dual GbE, 10/100/1000 Mbps (Realtek RTL8111G-CG)
Audio Chipset Realtek ALC662 High Definition Audio (HD)
Connector Line out
Storage SATA II 1 Internal 2.5” HDD/SSD
Power Power Supply Voltage 9-36 V DC input (Phoenix Connector
Power Adaptor AC-to-DC, 12 V @ 5 A, 60 W
Power Consumption (Typical) 1.45A @ 12V (17.4W)
Power Consumption (Max) 1.72A @ 12V (20.7W)
Battery Lithium 3 V / 210 mAH
Environment Operating Temperature 0~50° C (32~122° F) w/ 2.5” SSD
Storage Temperature -40~85° C (-40~185° F)
Humidity 5~95% @ 40° C, non-condensing
Vibration 5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Certification CE, FCC Class A
General Front Panel Waterproof IP65, stainless steel front cover
Dimensions (L x W x H) 359.3 x 297.3 x 71.52 mm (14.15” x 11.7” x 2.82”)
Weight 3.32kg (7.30lb)
Operating System Windows 7/8, WS7E/P, WES8

Packing List

Description
1 x PPC-S122
1 x Driver CD
1 x Power Adaptor (AC-to-DC, 12 V @ 5 A, 60 W)
12 x Panel Mounting Screws

Ordering Information

Part No. Description
PPC-S122P-1A1 12.1” Fanless Multi-touch Panel PC with IP65 Protection, and Intel® Celeron® J1900 2.0 GHz Processor
PPC-S122R-1A1 12.1” Fanless Resistive Touch Panel PC with IP65 Protection, and Intel® Celeron® J1900 2.0 GHz Processor

Optional Items

Part No. Description
ACS-PS-US Power cable: 3-pin, 180 cm, USA Type
ACS-PS-EU Power cable: 3-pin, 180 cm, Euro Type
ACS-PS-CN Power cable: 3-pin, 180 cm, China Type
ACS-100-STD VESA Table Stand

Datasheet

Type Description File Name File Size
PDF Datasheet of PPC-S122 (English) DS_Arestech_PPC-S122.pdf 1.1 MB
PDF

Datasheet of PPC-S122

(Traditional Chinese)

DS_Arestech_PPC-S122_ch.pdf 1.2 MB
PDF

Datasheet of PPC-S122

(Simplified Chinese)

DS_Arestech_PPC-S122_cn.pdf 1.3 MB
